Details of Wondcon WMV250B Veterinary Syringe Pump
DETAILS
Double CPU,double channel
Feature:
● Injection accuracy of up to ±2%
● Anti-bolus and anti-siphon functions increase patient safety
● Various visual and audible alarms
● Automatically record historical setting parameters to save clinical operation time
● Available change the infusion parameters without interruption of infusion
● Keyboard locking function to prevent misoperation
● Automatic identification of syringe specifications, suitable for different brand syringes
● Button and shuttle key double input mode, to meet different users
● Double screen,double CPU
● Four infusion mode for choose
● History record 50000 events
● 12 months warranty
SPECIFICATION
Syringe Size
10, 20, 30, 50/60 ml
KVO Rate
0.1-1 ml/h (in 0.1 ml/h increments)
Applicable Syringe
Compatible with syringe of any standard
Drug Library
Available
VTBI
0.1-10000 ml
＜1000 ml in 0.1 ml increments
≥1000 ml in 1 ml increments
Additional Features
Real-time infused volume, automatic power switching,
automatic syringe identification, mute key, purge, bolus,
anti-bolus, system memory
Flow Rate
Syringe 10 ml: 0.1-420 ml/h
Syringe 20 ml: 0.1-650 ml/h
Syringe 30 ml: 0.1-1000 ml/h
Syringe 50/60 ml: 0.1-1600 ml/h
＜100 ml/h in 0.1 ml/h increments
≥100 ml/h in 1 ml/h increments
Infusion mode
Memory mode
Flow rate mode: ml/min, ml/h
Time-based mode
Body weight mode: mg/kg/min, mg/kg/h, ug/kg/min,
ug/kg/h etc.
Bolus Rate
Syringe 10 ml: 200-420 ml/h
Syringe 20 ml: 300-650 ml/h
Syringe 30 ml: 500-1000 ml/h
Syringe 50/60 ml: 800-1600 ml/h
Alarm
Occlusion, near empty, end program, low battery, end
battery,AC power off, motor malfunction, system
malfunction, reminder alarm, pressure sensor error,
syringe installation error, syringe drop off
Anti-Bolus
Automatic
Accuracy
±2% (mechanical accuracy ≤1%)
Occlusion
Sensitivity
High, medium, low
Battery
Battery life:7 hours at 5 ml/h
Battery:9.6±1.6 V, rechargeable
Power supply AC:110/230 V (optional), 50/60 Hz, 20 VA
Weight & Size
4.5 kg,330*125*225 mm
Working Temperature
Temp:5-40℃,Relative Humidity 20-90%
Safety Classification
Class Ⅱ, type CF
Atmospheric Pressure
860-1060 hpa
