Description of Wondcon WMV250A Veterinary Syringe Pump
DETAILS
Safe, accurate and easy-to-use.
Great for use in veterinary pain management, anesthesia, and oncology areas.
Feature:
● Injection accuracy of up to ±2%
● Anti-bolus and anti-siphon functions increase patient safety
● Various visual and audible alarms
● Automatically record historical setting parameters to save clinical operation time
● Available change the infusion parameters without interruption of infusion
● Keyboard locking function to prevent misoperation
● Automatic identification of syringe specifications, suitable for different brand syringes
● Button and shuttle key double input mode, to meet different users
● Horizontal design allows you to stack multiple pumps on a single IV pole
● Four infusion mode for choose
● 12 months warranty
SPECIFICATION
Syringe Size
10, 20, 30, 50/60 ml
KVO Rate
0.1-1 ml/h (in 0.1 ml/h increments)
Applicable Syringe
Compatible with syringe of any standard
Drug Library
Available
VTBI
0.1-9999 ml
＜1000 ml in 0.1 ml increments
≥1000 ml in 1 ml increments
Additional Features
Real-time infused volume, automatic power switching,
automatic syringe identification, mute key, purge, bolus,
anti-bolus, system memory
Flow Rate
Syringe 10 ml: 0.1-400 ml/h
Syringe 20 ml: 0.1-600 ml/h
Syringe 30 ml: 0.1-900 ml/h
Syringe 50/60 ml: 0.1-1300 ml/h
＜100 ml/h in 0.1 ml/h increments
≥100 ml/h in 1 ml/h increments
Infusion mode
Memory mode
Flow rate mode: ml/min, ml/h
Time-based mode
Body weight mode: mg/kg/min, mg/kg/h, ug/kg/min, ug/kg/h etc.
Bolus Rate
Syringe 10 ml: 400 ml/h
Syringe 20 ml: 600 ml/h
Syringe 30 ml: 900 ml/h
Syringe 50/60 ml: 1300 ml/h
Alarm
Occlusion, near empty, end program, low battery, end
battery,AC power off, motor malfunction, system
malfunction, reminder alarm, pressure sensor error,
syringe installation error, syringe drop off
Anti-Bolus
Automatic
Accuracy
±2% (mechanical accuracy ≤1%)
Occlusion
Sensitivity
High, medium, low
Battery
Battery life:7 hours at 5 ml/h
Battery:9.6±1.6 V, rechargeable
Power supply AC:110/230 V (optional), 50/60 Hz, 20 VA
Weight & Size
2.5 kg,314*167*140 mm
Working Temperature
Temp:5-40℃, Relative Humidity 20-90%
Safety Classification
Class Ⅱ, type CF
Atmospheric Pressure
860-1060 hpa
