Product Name:Wondcon WMV680E Veterinary Anesthesia Machine
Model:WMV680E
Application:Vet hospital,clinic(dog,cat etc)
Inquiry:

Description of Wondcon WMV680E Veterinary Anesthesia Machine


Features:

The compact Wondcon WMV680E Veterinary Anesthesia Machine is designed for office-based surgery centers and small facilities in which space is at a premium. Compact for mobility and cost-effective to save you money, the WMV680E model has integrated safety functions and is easy to use and maintain.

Specification:

● Driven mode: Pneumatically driven Electrolytically controlled
● Main body: High-strength engineering plastic rack, light, beautiful and corrosion resistant
● Vaporizer: Two Vaporizers from Halothane, Enflurane, Isoflurane, and Sevoflurane
  Automatic compensation for pressure, temperature and flow rate.
● Gas Source: O2: 0.27~0.55MPa    N2O: 0.27~0.55MPa
● Flow meter: O2 or O2/N2O flowmeter   O2 :1~10L/min  N20:1~10L/min
● O2, N2O linkage and N2O Stopper:
  When using nitrous oxide, oxygen concentration>25%;
  When the oxygen pressure<0.2Kpa, the flow of nitrous oxide would be cut off O2 flush:25-75L/min
● Low oxygen pressure alarm: There will be sound alarm when the oxygen pressure< 0.2MPa
● Respiratory circuit: All-close, semi-close, semi-open
● APL:0.5~7 kPa
● Security Alarm System:
  1) Oxygen Concentration alarm
    Upper limit setting range: 21%~100%
    Low limit setting range: 10%~80%
  2) Airway pressure alarm
    Upper limit setting range: 0.3~6.0 kPa
    Low limit setting range: 0.2~5.0 kPa

Standard Configuration:

One unit portable anesthesia machine, transport case, one vaporizer,
one set breath circuit

Optional Configuration:

Anesthesia ventilator, trolley
