Description of Wondcon WMV690A Veterinary Anesthesia ventilator

DETAILS

Integrated patient alarms improve patient safety

Features:

WMV690A veterinary anesthesia ventilator is an excellent vet anesthesia ventilator, it has pressure limited

protect function.

It is used for small animal with veterinary anesthesia machine.

SPECIFICATION

● Pneumatically driven electronically control

● Mode: IPPV(automatic ventilation)

● Tidal volume: 50-1500ml, knob setting

● Breath frequency: 3-60BPM

● I:E: 3:1, 2:1, 1:1, 2:3, 1:2, 1:3

● Monitor: Inspiration indication Power indication

● Pressure limited protect: 0-60cmH2O

● Gas source: 0.4Mpa O2 or Air

● Power supply: 220V, 50HZ or 110V, 60HZ

STANDARD CONFIGURATION

Anesthesia ventilator with 300ml or 1500ml bellow

Silicon corrugated hose(Φ22*300mm)

Silicon corrugated hose(Φ22*1000mm)

O2 gas source pipeline

Power supply

OPTIONAL CONFIGURATION

Animal mask

Bird mask

Laryngoscope

Endotracheal intubation

Rescue and Resuscitation

Bains breathing circuit

T-piece anesthesia breathing circuit

Reusable breathing bag

Disposable absorber of anesthesia exhaust gas

Anesthesia machine

ETCO2 monitor SPO2 monitor Patient monitor

Oxygen concentrator

Oxygen concentrator-anesthesia machine Stand

Anesthesia machine-ventilator stand

Induction Chambers
