Product Name:Wondcon WMV690B Veterinary Anesthesia ventilator
Model:WMV690B
Application:
Inquiry:

Description of Wondcon WMV690B Veterinary Anesthesia ventilator

DETAILS

Features:

Wondcon WMV690B Veterinary Anesthesia ventilator is a pneumatically driven anesthesia ventilator for use with both large and small animals.


SPECIFICATION

● Pneumatically driven electronically control
● HD LCD Adult bellow(0-1500ml) or pediatric bellow(0-300ml)
● Ventilation mode:IPPV,Manual
● Display: HD LCD digital display
● Monitoring: Tidal volume,breathing rate, I:E ratio, Peak airway pressure,
● TV: 50~1600ml
● Digital Anesthesia ventilator
● Breathing rate: 4~60bpm
● I:E ration: 1:1~1:4 adjustable
● Upper airway pressure: 2~6kpa
● Lower airway pressure: 0.6~2kpa
● Alarm information: Sound and light alarm
● Pressure high/low alarm, Tidal volume high/low alarm,
   Apnea alarm Others: Silence for 2 minutes
● Gas source: 0.4Mpa O2 or Air
● Power supply: 220V, 50HZ or 110V,60HZ


STANDARD CONFIGURATION

Anesthesia ventilator with 300ml or 1500ml bellow
Corrugated hose(Φ22X1000mm)
Corrugated hose(Φ22X30mm)
O2 gas source pipeline
Power supply
Flow sensor

OPTIONAL CONFIGURATION

Animal mask
Bird mask
Laryngoscope
Endotracheal intubation
Rescue and Resuscitation
Bains breathing circuit
T-piece anesthesia breathing circuit
Reusable breathing bag
Disposable absorber of anesthesia exhaust gas
Anesthesia machine
ETCO2 monitor SPO2 monitor Patient monitor
Oxygen concentrator
Oxygen concentrator-anesthesia machine Stand
Anesthesia machine-ventilator stand
Induction Chambers
