Description of Wondcon OSL 314 LED Surgery Light

DETAILS

Wondcon OSL 314 series LED Operation shadow less lamp provides bright, consistent illumination and excellent engineering.

Feature:

● Intelligent touch screen

● The removable handle sheath can be cleaned and disinfected.

● The imported switch power supply is adopted to control the voltage, making the working

  voltage permanently stable.

● Adjustable temperature, R9 features that enhance the red color rendering index.

● With the function of minimally invasive lighting and brain surgery lighting.

● LED shadow less lamp life expectancy long (50000h)

SPECIFICATION

Illumination at 1m(lux): 160000

Optional color temperature (K): 6700K≥Tc≥3500k

Illumination at 1m(lux)on endo model(lux): 15000

Heat to light ration(m W/m2 lx): ＜6

Light field diameter D10 mm: 180±40/180±40

Power supply : 110-240V

D50 mm: 110±35/110±35

Input power (VA): 180

Depth of illumination L1+L2 mm:150

R11 ≥97

Color rendering index(RA) 100≥Ra≥85

R13 ≥99

Red color index R9 R9≥97

R15 ≥98

Average bulb life(hours) : 50000h

Ceiling height for installation(cm) : 270-320

Number of LEDS : 84/84

Warranty: 12months

OPTIONAL CONFIGURATION

1. Video Camera: 1080P High definition

2. Monitor Arm: Provides options for Hi-Def

3. Solo arm or in combination with lights
