Description of Wondcon OSL 316 LED Surgery Light

DETAILS

Wondcon OSL 316 series LED Operation shadow less lamp is multiple configurations to fit your operating room needs.

Features:

● Cool output LED light source

● The removable handle sheath can be cleaned and disinfected

● Cost efficient surgery lighting system

● 50,000 hour rated LED life

● Available in a single or dual head ceiling mount

● 12 months warranty

SPECIFICATION

Diameter of light head (cm) : Combined type

Average bulb life(hours) 50000h

Illumination at 1m(lux) 80000-160000

Number of LEDS: 72/72

Light field diameter at 1m(cm): 10-28

Optional color temperature (K): 6700K≥Tc≥3500k

Light field diameter D10 mm: 180±40/180±40

Heat to light ration(m W/m2 lx): ＜6

D50 mm: 110±35/110±35

Power supply: 110-240V

Depth of illumination L1+L2 mm: 150

Input power (VA) 180

Color rendering index(RA): 100≥Ra≥85

Ceiling height for installation(cm): 270-320

Working distance(cm): 70-140

Warranty: 12 months

OPTIONAL CONFIGURATION

1. Video Camera: 1080P High definition

2. Monitor Arm: Provides options for Hi-Def

3. Solo arm or in combination with lights.
