Description of Wondcon WMV200A Veterinary Infusion Pump

DETAILS

Safe, accurate and easy-to-use.

Great for use in veterinary pain management, anesthesia, and oncology areas.

Features:

● Injection accuracy of up to ±2%

● Anti-bolus and anti-siphon functions increase patient safety

● Various visual and audible alarms

● Automatically record historical setting parameters to save clinical operation time

● Available change the infusion parameters without interruption of infusion

● Keyboard locking function to prevent misoperation

● Automatic identification of syringe specifications, suitable for different brand syringes

● Button and shuttle key double input mode, to meet different users

● Horizontal design allows you to stack multiple pumps on a single IV pole

● Four infusion mode for choose

● 12 months warranty

SPECIFICATION

Pumping Mechanism

Curvilinear peristaltic

Occlusion Sensitivity

5 levels

IV Set

Compatible with IV sets of any standard

Air-in-line Detection

Ultrasonic detector

Flow Rate

1-1100 ml/h (in 1 ml/h increments)

Power Supply, AC

110/230 V (optional), 50-60 Hz, 20 VA

Purge, Bolus

Purge when pump stops, bolus when

pump starts, rate at 700 ml/h

Battery

9.6±1.6 V, rechargeable

Accuracy

±3%

Battery Life

5 hours at 30 ml/h

VTBI

1-9999 ml

Working Temperature

10-40℃

Infusion Mode

ml/h, drop/min

Relative Humidity

30-75%

KVO Rate

4 ml/h

Atmospheric Pressure

700-1060 hpa

Alarms

Occlusion, air-in-line, door open, end program, low battery, end battery, AC power off, motor malfunction, system malfunction, reminder alarm

Additional Features

Real-time infused volume, automatic power switching, Mute key, purge, bolus,

system memory

Size & weight

174*126*215 mm 2.5kg

Safety Classification

Class I, type CF
