Description of Wondcon WMV200C Veterinary Infusion Pump

DETAILS

Complete, efficient infusion for your facility.

Equipped with safety alarm settings and an incorporated anti-bolus system, Wondcon WMV200C model compact and portable,fast speed regulation ,perfect for ambulance use.

Features:

● Full-featured infusion pump operates in two modes :Vol/rate mode

● Compatible with straight line tubing sets from any manufacturer.

● Calibrate and save up to five different line sets.

● Onboard alarms sound in case of: air bubbles, infusion completion, downstream occlusion,

  no AC power, low battery and more

● Limited 2-year warranty.

● With an easy user interface you can

● set all functions with just four buttons

SPECIFICATION

Pumping Mechanism

Curvilinear peristaltic

Occlusion Sensitivity

0.1-0.14 Mpa, adjustable

IV Set

Compatible with IV sets of any standard

(Ф3.8mm±0.2mm, δ<0.5mm)

Air-in-line Detection

Ultrasonic detector

Flow Rate

1-1100 ml/h in 1 ml/h increments

Power Supply, AC

110/230 V (optional), 50-60 Hz, 20 VA

Purge, Bolus

Purge when pump stops, bolus when pump starts Rate at 700 ml/h

Battery

AC: 230 V, 50 Hz

Battery: 9.6±1.6 V, rechargeable

Vehicle power: 12±1.2 V

Accuracy

Universal IV set: ±5%

Battery Life

3 hours at 30 ml/h

VTBI

1-9999 ml in 1ml increments

Working Temperature

10-30℃

Infusion Mode

ml/h, drop/min

Relative Humidity

30-75%

KVO Rate

4ml/h

Atmospheric Pressure

860-1060 hpa

Alarms

Occlusion, air-in-line, door open, end program,low battery,unattended pump after

startup, system malfunction

Additional Features

Real-time shift totals, automatic power

switching,mute button, purge, bolus

Size & weight

130*145*228 mm 2.5kg

Safety Classification

Class Ⅰ, type CF

Optional

Infusion Management System,drop sensor
