Description of Wondcon WMV200D Veterinary Infusion Pump
DETAILS
Compact and portable,fast speed regulation for ambulance use.
Equipped with safety alarm settings and an incorporated anti-bolus system,
The setting parameter can be set fast, perfect for ambulance use.
Features:
● Full-featured infusion pump operates in five modes: ml/h,drop/min,time-based, body
weight, enteral feeding
● Compatible with straight line tubing sets from any manufacturer.
● Calibrate and save up to five different line sets.
● Onboard alarms sound in case of: air bubbles, infusion completion, downstream occlusion,
no AC power, low battery and more.
● Limited 2-year warranty.
● With an easy user interface
DESCRIPTION
Pumping Mechanism
Curvilinear peristaltic
Occlusion Sensitivity
H: 0.06-0.11 Mpa, M: 0.09-0.14 Mpa, L: 0.13-0.18 Mpa
IV Set
Compatible with IV sets of any standard (Ф3.8mm±0.2mm, δ<0.5mm)
Air-in-line Detection
Ultrasonic detector
Flow Rate
1-1200 ml/h (1-100 ml/h in 0.1 ml/h increments)
Power Supply, AC
110/230 V (optional), 50-60 Hz, 20 VA
Purge, Bolus
Purge when pump stops, bolus when pump
starts.Adjustable rate at 500, 800, 1200 ml/h
Battery
AC: 230 V, 50 Hz,Battery: 9.6±1.6 V, rechargeable
Vehicle power: 12±1.2 V
Accuracy
Universal IV set: ±5%
Battery Life
3 hours at 25 ml/h
VTBI
1-20000 ml (1-100 ml in 0.1 ml increments)
Working Temperature
10-30℃
Infusion Mode
ml/h, drop/min, time-based, body weight, enteral feeding
Relative Humidity
30-75%
KVO Rate
1-5 ml/h in 0.1 ml/h increments
Atmospheric Pressure
860-1060 hpa
Alarms
Occlusion, air-in-line, door open, end program, low battery,unattended pump after startup, system malfunction
Additional Features
Real-time shift totals, automatic power switching,mute
button, purge, bolus, history log, system memory
Size & weight
130*145*228 mm 2.5kg
Safety Classification
Class Ⅰ, type CF
Optional
Infusion Management System, drop sensor
