Description of Wondcon WMV200E Veterinary Infusion Pump

DETAILS

Mini size,light weight,easy operation.

Features:

● History records

● Four operation modes:Rate mode,drip mode,time mode,body weight mode.

● Anti-reverse rotation detection Various visual and audible alarms Double CPU ensuring safe

  infusion

● Real time display

● 3 adjustable occlusion pressure settings

● Removable pump body,convenient for cleaning

● 12 months warranty

SPECIFICATION

Pumping Mechanism

Curvilinear peristaltic

Occlusion Sensitivity

low, middle and high

IV Set

Support a wide variety brands of infusion set including major manufacturers & selected local brands

Air-in-line Detection

Ultrasound sensor detection with four levels of air in line alarm adjustable

Flow Rate

0.1~1200 ml/h

Power Supply, AC

110/230 V (optional), 50-60 Hz, 25VA

Purge, Bolus

Purge when pump stops, bolus when pump starts. Bolus rate 300 ~ 1200 ml/h, purge rate 600ml/h

Battery

Rechargeable lithium polymer battery,7.4V,2100mAh

operating time:about 6 hours at 25ml/h

Charging time:10hs with power on, 3hs with power off.

Accuracy

Universal IV set: ±5%

Battery Life

3 hours at 25 ml/h

VTBI

0 ~ 9999 ml

Working Condition

Temperature:5℃~40℃,relativehumidity:10~95%, air pressure:86~106kPa

Infusion Mode

rate mode, drip mode,time mode,body weight mode

Relative Humidity

30-75%

KVO Rate

1 ~ 5 ml/h

Atmospheric Pressure

860-1060 hpa

Alarms

Visual and audible alarms: Door open, Air-In-Line, Occlusion,

Infusion completion, infusion near over, Start reminder function,

Low Battery, Battery depleted, malfunction etc.

Additional Features

Real-time shift totals, automatic power switching,mute

button, purge, bolus, history log, system memory

Size & weight

145×100×120 mm(length×width×height) 1.4kg

Safety Classification

ClassⅠ, type CF

Volume Infused

0-36000ml

Water Proof Level

IPX3
