Description of Wondcon WMV 650B Veterinary Patient Monitor
DETAILS
Accuracy and durability, Mindry quality for OR,ICU,CCU use.
Features:
● 12 inch high resolution touchable display for easy reading
● Portable design and user-friendly interface for easy operation
● Flexible configurations to meet different clinical needs
● Optional IBP,ETCO2,CO,VGA,printer
● Optional CMS function,up to 64 beds
● Optional wifi/3G/4G module
● Built-in rechargeable Lithium-ion battery for fluid
● Built-in rechargeable battery
● 7 hours continuous working with battery
● 12 months warranty
SPECIFICATION
Standard configuration specification
Display
12.1” color TFT LCD touch
Screen,resolution: 800 x 600
8 waveform display,12-leads ECG Display
I/O
LAN: 1 standard RJ45 port
WLAN: IEEE802.11b/g/n
USB:2 USB connectors
SD: 1 SD card socket
Output:1 connector for nurse
call,Defib sync analog output
VGA: 1 color VGA monitor
connector(optional)
RESP
Method:Trans-thoracic impedance
Operation modes: Auto/Manual
Measurement range: Adult:0~150 bmp
TEMP
Accuracy: ±0.1℃ or ±0.2℃ °F
（without probe）
Measurement range: 5~50℃
（41~122°F）
Channel:Two channels
Resolution: 0.1℃
Parameters:T1,T2 and TD
Pulse rate
Range: 30~254 bpm
Resolution: 1bpm
Accuracy: ±3bpm (non-motion)
±5bpm (motion)
Refreshing rate: 1s
SPO2
Measurement range : 0-100%
Resolution: 1%
Accuracy: ±2%（70-100% Cat/Dog);
±3%（70-100%,Others);
0-69%,unspecified Refreshing Rate: 1s
Pulse rate
Range: 30~254 bpm
Resolution: 1bpm
Accuracy: ±3bpm (non-motion)
±5bpm (motion)
Refreshing rate: 1s
NIBP
Measurement method : Automatic oscillometric method
Operating mode:Manual, automatic, continuous
Measurement unit: mmHg/kPa selectable
Typical measurement time: 20~40s
Measurement type: Systolic, Diastolic,Mean
Measurement range (mmHg)
Range of Systolic pressure: Dog 40-270, Cat 40-200, Others 40-135
Range of Diastolic pressure: Dog 10-210, Cat 10-150, Others 10-95
Range of Mean pressure: Cat 20-230, Dog 20-165, Others 20-105
Measurement accuracy
Maximum average error: ±5mmHg
Maximum standard deviation: 8mmHg
Resolution: 1mmHg
Interval:1,2,3,4,5,10,15,30,60,90,120,180,240,480 minutes
Over pressure protection: Software and
hardware,double
safety protection
Cuff pressure range: 0-280mmHg
Operation environment
Power: AC 100-250V, 50/60Hz
Temperature: 5-40℃
Humidity: ＜85%
Optional Configuration Specification
IBP Optional
Channel:2-channel or 4-channel
ART: 0 to 300 mmHg
PA: -6 to 120 mmHg
CVP/RAP/LAP/ICP : -10 to 40 mmHg
Measurement range: P1/P2 -50 to 300 mmHg
Resolution:1mmHg
Accuracy: ±2% or ±1mmHg, whichever is greater(without sensor)
Sensitivity: 5uV/mmHg/V
Impedance range: 300 to 3000Ω
C.O. Optional
Method: Thermodilution
Range: C.O.: 0.2 to 20 L/min
TB: 23 to 45 ℃
T1: -1 to 27℃
Accuracy:C.O.:±5% or ±0.1L/min，whichever is greater
TB, T1：±0.5℃ (without sensor)
Masimo IRMATM Mainstream CO2 (optional)
Measurement Range: 0 -25%
Warm-up time: Full accuracy within 10 seconds
Accuracy: 0~15% (±0.2% of the reading)
15~25%, unspecified
AWRR Range: 0-150bpm
VGA/HDMI(Optional)
Connector to TV monitor
WIFI/3G/4G module
Connect internet
CMS system
At most up to 64 units
Recorder(optional)
Built-in,Thermal dot array
Horizontal resolution :16 dots/mm (25 mm/s paper
speed)
Vertical resolution:8 dots/mm
Paper speed:25 mm/s, 50 mm/s
Number of waveform channels:3ptional)
STANDARD CONFIGURATION
SPO2+NIBP+PR+ECG+RESP+Temp
Main unit with SPO2, NIBP, ECG, T1/T2 port
Reusable veterinary cuff(5 sizes)
Animal SPO2 line 2 pieces
Temperature line
ECG line
OPTIONAL CONFIGURATION
Stand or wall type
Thermal recorder
IBP
ETCO2
WIFI/3G/4G module
CO
