Description of Wondcon WMV680F Veterinary Anesthesia Machine
Feature:
The compact Wondcon WMV680F Veterinary Anesthesia Machine is designed for office-based surgery centers and small facilities in which space is at a premium.portable anesthesia system ideal for traveling vets, and office-based surgery centers and small facilities in which space is at a premium.
WMV680F model saves time during mobile animal hospital rescues, field research, and house calls. Cost-effective to save you money, it has integrated safety functions and is easy to use and maintain.
Specification:
● Respiration mode:Manual,open,closed,semi-open and semi-closed mode
● Gas source:O2,0.3--0.4Mpa
O2 Flush:25L/min- -75L/min
● Tidal Volume: 0-2000ml
● Flow meter: high precision O2 flow meter, 0--1L/min--10L/min, O2&N2O or
O2&N2O two tubes flow meter is option.
● CO2 circle absorber:with 1.8L soda lime chamber, APL valve, airway pressure
gauge, inspiration valve and expiration valve, the inspiration and expiration valve
is demo-type and visible.
● Soda lime chamber: High quality poly carbonate material, which is very strong and not broken.
● Airway pressure gauge: -20cmH2O--100cmH2O &-2Kpa--10Kpa
● APL valve:adjustable easily, range:0-60cmH20
● Soda lime chamber:1.8Liter or 0.8L, it is easy to change soda lime and used for 0.5-100KG animal
● Three methods:table top and trolley and wall mounting arm, trolley is optional and wall mounting arm is optional.
● Bains connector:it is used for open breath circuit, connect with Jackson breath circuit or bains breath circuit.
● Back bar:Supply selectatec compatible mounting bar,ISO 23mm is compatible
● Anesthesia vaporizer: TEC3 vaporizer. Enflurane, Isoflurane, Halothane,
Sevoflurane, one vaporizer with selectatec compatible mounting bar, Cage
mounting vaporizer is compatible.
● Trolley: There is a trolley to support and veterinary anesthesia machine. The trolley is optional.
Standard configuration:
Anesthesia machine with vaporizer
Disposable breath circuit
Reserve bag
O2 gas source pipeline
Stand
Optional configuration:
Animal mask
Bird mask
Laryngoscope
Endotracheal intubation
Rescue and Resuscitation
Bains breathing circuit
T-piece anesthesia breathing circuit
Reusable breathing bag
Disposable absorber of anesthesia exhaust gas
Anesthesia ventilator
ETCO2 monitor SPO2 monitor Patient monitor
Oxygen concentrator
Oxygen concentrator-anesthesia machine Stand
Anesthesia machine-ventilator stand
Induction Chambers
