Description of Wondcon WMV 630A Veterinary Electrosurgical Unit

DETAILS

Excellent solution for veterinary facilities seeking a full-featured electrosurgery generator at an economical price point.

Features:

● Durable, water-proof foot pedals

● Stable,using over 3 years,almost zero maintenance rate

● The wide scope permanent power, the surgery locates precisely

● The return route pole plate monitor system, guarantees the patient safety

● There are three kinds of sound to show the 4 different working modes as the following:

  Error Warning, Cutting & Coagulation, Bipolar

● When turn on the Generator, it can check the system by itself 350W high efficiency output

  also continuously adjustable, can meet each kind of surgeon’s surgery needs. (General

  surgery, thoracic surgery)

● Six kinds of working model, the surgery is quickly easy

● When the neutral electrode detect that the impendence is between 20Ω and 140Ω, the

  alarm will be activated and the ESU will be shut down

● 36 months warranty

SPECIFICATION

Working Modes and Max Power of Monopolarmode

Pure Cut 350W(Load500Ω)

Blend Cut 1 200W(Load500Ω)

Blend Cut 2 120W(Load500Ω)

Spray Coag 150W(Load500Ω)

Soft Coag 80W(Load 500Ω)

Working Modes and Max Power of Bipolar mode

Standard Bipolar Coag 70W(Load 100Ω)

Power Consumption ≤1100VA(Cutting function 350W, Bipolar coagulation function 70W output )

Power 220V±22V(110V±11V),50Hz±1Hz

Operating frequency 360～460kHz

Power rating 1100VA±10%

STANDARD CONFIGURATION

Electrosurgical Unit 1

Power Line 1 piece

Electrosurgical Pencil 2 piece

Bipolar Forceps 1 piece

Bipolar Forceps Cable 1 piece

Single Patient Plate 3 piece

Patient Plate Cable 1 piece

Waterproof Footswitch 1 piece

GBXP5*20(5/10A) Fuse: 2 pieces

Packing List: 1 piece
