Description of Wondcon WMV 620A Veterinary Surgical Table

DETAILS

The table features a built-in warming system and is electric base. and comes with a stainless steel.

Features:

● Stainless material.Corrosion protection. anti-breakage

● Weight Capacity: 400IBS(equal to 181kg)

● Warming system. Avoid animal feel cold during surgical operation

● Smooth lowering and lifting function

● Adjustable floor glides

● 12 months warranty

SPECIFICATION

Parameter

1. Table height:760－1060mm

2. Table dimension: 1400X650mm

3. Table gradient:±15°

4. Adjustable angle of table board:0°~45°

5. The range of temperature:0°~50°

6. Power: 220V

Production and Performance

1. Composed of table-board. pin. and table pedestal. equipped with surgical instruments

   bracket, tray and infusion support.

2. Made of stainless steel. table pedestal adopts rolling design. can move easily and has fixed-lock bolt.

Structure Diagram

1. Adjust bolt

2. Universal wheel

3. Pedestal

4. Foot switch

5. Power switch

6. Temperature control gauge

7. Drain port

8. Overturn lock nut

9. Tray

10. Infusion support

11. Pin shaft

12. Table board

13. Incline lock nut

14. Adjust hand wheel

15. Case
