Description of Wondcon WMV 620B Veterinary Surgical Table

DETAILS

The table features a Hydraulic base, and comes with a stainless steel.

Warming system can choose depends on customer required

Features:

● Stainless material,Corrosion protection, anti-breakage

● Hydraulic system

● Weight Capacity:400IBS(equal to 181kg)

● Warming system is available.

● Smooth lowering and lifting function

● Adjustable floor glides

● 12 months warranty

---

    SPECIFICATION

Parameter

1. Table height:820－930mm

2. Table dimension: 1400X650mm

3. Table gradient:±15°

4. Adjustable angle of table board:0°~45°

5. The range of temperature:0°~50°(Optional)

6. Power: 220V

Production and Performance

1. Composed of table-board. pin. and table pedestal. equipped with surgical instruments bracket,

    tray and infusion support.

2. Made of stainless steel. table pedestal adopts rolling design. can move easily and has fixed-lock bolt.

Structure Diagram

1. Adjust bolt

2. Universal wheel

3. Pedestal

4. Foot switch

5. Power switch

6. Temperature control gauge

7. Drain port

8. Overturn lock nut

9. Tray

10. Infusion support

11. Pin shaft

12. Table board

13. Incline lock nut

14. Adjust hand wheel

15. Case

Before order, please choose whether or not need heating function. Thanks!
