Description of Wondcon WMV630B Vessel Sealing And Cutting System Generator
DETAILS
WMV630B Vessel Sealing System integrates a vessel sealing system and bipolar
electrosurgery, allowing clinicians to complete a wide va riety of procedures with
just one unit. Clinical Benefits for Both the Surgeon and Patient
Features:
● Permanently fuses vessels up to and including 7 mm in diameter
● Tissue bundles without dissection or isolation
● Reduces the risk of needlestick injuries,reduces thermal spread,minimizes thermal spread to
approximately 1~ 2 mm for most instruments.
● Unique energy output results in virtually no sticking or charring
● Permanent seal leaves no foreign material behind to interfere with future diagnosis
● A clinical study demonstrated that seals withstand 3x normal systolic blood pressure
● May reduce blood loss in some surgical procedures. Minimizes the need for multiple
applications
● Permanent seal leaves no foreign material behind to interfere with future diagnosis
● 12 months warranty
● Real time Instant
● power technology features an advanced feedback system that recognizes changes in tissue
1,000 times per second.
● The generator automatically senses tissue resistance and adjusts the output voltage to
maintain a consistent effect across different tissue density.
● This adjustment is based on the power setting and the leve loft issue resistance. The maximum
output voltage is controlled to reduce tissue damage and to minimize sparking. The generator
produces a high current, low-voltage output that corresponds to at least four times the
current of a standard electrosurgery generator, with one-fifth to one-twentieth the amount
of voltage.
SPECIFICATION
Brief
Two touch screen, two sockets
Main carrier frequency
457KHz
Related power output
5 levels as 100W,120W,140W,160W,180W
Unit Dimension
480mm(L)×400mm (W) ×140mm(H)
Working condition
Temperature: 10℃～40℃
Humidity: 30%～75%
Atmospheric pressure: 700hPa～1060hPa
Power supply
220V/110V ±22V, 50Hz±1Hz
