Description of Wondcon WMV 660C Six Channels ECG Machine

DETAILS

Accuracy and durability, for OR,ICU,CCU animal use

Features:

● 7 leads synchronously acquisition and record, excellent auto-interpretation function

● High accuracy digital filter, auto-baselineadjustment

● Working modes: Manual/ Auto / R-R Rhythm

● Recording mode: 3ch+, 3ch+++, 6ch

● 112mm*20m high resolution thermal printing

● 250 cases storage and replay

● Built-in rechargeable

● Ni-MH battery supports continuous work for about 4 hours.

● 800×480 graphic 7 inch color touch LCD to display detailed ECG information

● Rs232 and USB interface ( USB disk storage, laser printer printing , Veterinary PC ECG software

  are optional )

● SD card storage is optional

● 12 months warranty

---

     SPECIFICATION

Lead

Standard 7 leads

Time constant

≥3.2s

lead acquisition

12bit/1000Hz (synchronously 7 leads)

Frequency response

0.05～160Hz(-3db)

Work mode

Man / Auto/R-R Rhythm

Noise level

＜15μVp-p

Filter

AC Filter : 50Hz / 60Hz

EMG Filter : 25Hz / 45Hz

Anti-Drift Filter : 0.15Hz (Adaptive)

Inter-channel Interference

≤0.5mm

CMMR

≥120dB (with AC FILTER)

Sensitivity

2.5，5，10，20, 40, Auto (mm/mV)

Input circuit

Floating; Protection circuit against

Defibrillator effect

Recording mode

3ch+, 3ch+++, 6ch

Default Man. Mode is 3ch+++ format

Default Auto. Mode is 6ch format

Input Impedance

≥50MΩ

Paper speed

6.25、12.5、25、50mm/s（±3％）

Input circuit current

≤0.05μA

Paper

112mm *20m Roll paper

Patient current leakage

＜10μA

Communication

RS232/ USB port

Calibrating voltage

1mV±2％

Power Supply

AC 75-265V(±10%),50/60Hz（±1Hz),40VA

DC Built-in rechargeable battery,14.4V(2000mAh)

Voltage tolerance

≥±500mV

Dimension/Weight

300mm×230mm×75mm / 2.8Kg

STANDARD CONFIGURATION

Main unit with accessory

Main unit 1 unit

Veterinary Patient Cable 1 pcs

Grounding cable 1 pcs

Paper axis 1 pcs

Thermal paper 1 roll

Fuse 2pcs

Power cord 1pcs

OPTIONAL CONFIGURATION

PC software 1pcs

SD card 1pcs
