Description of Wondcon WMS-35/50LB Table Top Steam Sterilizer

DETAILS

With the simplicity of one touch design all your sterilization and drying needs are fulfilled.Fully automatic

autoclave fills, sterilizes, exhausts and dries at the touch of a button.

Features:

● For 4~6 minutes rapidly sterilizing.

● Digital display of working status,touch type key.

● With 3 fixed cycles of water adding,temperature rising,sterilizing,drying steam discharging controlled

   automatically.

● The whole process of water adding,temperature rising,sterilizing,drying steam discharging controlled

  automatically.

● Steam-water inner circulation system:no steam discharge,and the environment for sterilizing will be clean and

  dry.

● Exhaust the cool air automatically.

● Safe protection of water lacking.

● Door safety lock system.

● With four stainless steel sterilizing plates.

● The chamber of the sterilizer is made of stainless steel.

● Automatically shut off with been reminding after sterilization.

● 12 months warranty

SPECIFICATION

MODEL TECHNICAL DATA

Wondcon WMS-35/50LB

Sterilizing chamber volume

35L: (φ300×500 mm)

50L: (φ340×550 mm)

Working pressure

0.22Mpa

Working temperature

134℃

Adjustment of temperature

105-134℃

Timer

0-99 min

Heat average

≤ ± 1℃

Power

2.7KW / AC220V 50Hz

Sterilizing plate

35L: 400×200×30 mm (4piece)

50L: 500×250×30 mm (4piece)

Dimension

35L: 730×550×510 mm

50L: 770×600×540 mm

Package dimension

35L:810×680×650 mm

50L: 880×730×700 mm

G. W/N.W

35L:90/73 kg

50L: 105/86 kg
