Description of Wondcon WMS122024DV Pulsating Vacuum Desktop Steam Sterilizer
DETAILS
Easy operation,safe, fast, performance stable. Good choose for animal hospital/clinic.
For 4~6 minutes rapidly sterilizing.
Digital display of working status, touch type key.
Application: Surgical, dental, eye equipment. Glassware medicine, cuture medium, biological dressing,food etc.
Features:
● Standard class B with three times vacuum and drying,the remaining temperature
of sterilized instrument less than 0.2%.
● LCD display working status,touch keys
● The vacuum data can reach -0.8bar,it fits various instrument,including package,
unpackaged, solid, hollow, multi-apertures and inset pipes.It makes sure the
instrument can be sterilized completely.
● Fully computer controlled LCD display bright show.The interface is modularized
panel for easy operation.
● It is installed with BOWIE&DICK which measures the penetration of water steam.
● It has vacuum test which can make sure the ability of vacuum testing.
● Fast and independent steam generator.
● Built-in mini printer which can record the sterilizing information
● Equipped with safety valve,safety lock door system.
● Pressure lock system,pressure or temperature overload protection alarm system.
● It inactivates the HIV,HBV,BSE,and bacillus efficiently.
● This product is designed for open water tank,water purification, sewage tank
separation,convenient and intuitive.
● Warranty 12 months
SPECIFICATION
Sterilizing chamber volume
12L(φ200×370 mm)
18L(φ250×360 mm)
24L(φ250×470 mm)
Working pressure
0.22Mpa
Working temperature
134℃
Adjustment of temperature
105-134℃
Timer
0-99 min
Heat average
≤ ± 1℃
Power
12L: 1.8 KW / AC220V 50Hz
18L: 2KW / AC220V 50Hz
24L: 2KW / AC220V 50Hz
Dimension
12L: 560 × 470 × 400 mm
18L: 560 × 470 × 400 mm
24L: 675 × 470 × 400 mm
Package dimension
12L: 655 × 560 × 495 mm
18L: 655 × 560 × 495 mm
24L: 765 × 560 × 495 mm
G.W/N. W
12L: 48/43 kg
18L: 52/47kg
24L: 58/53kg
