Description of Wondcon WMS122024DV Pulsating Vacuum Desktop Steam Sterilizer

DETAILS

Easy operation,safe, fast, performance stable. Good choose for animal hospital/clinic.

For 4~6 minutes rapidly sterilizing.

Digital display of working status, touch type key.

Application: Surgical, dental, eye equipment. Glassware medicine, cuture medium, biological dressing,food etc.

Features:

● Standard class B with three times vacuum and drying,the remaining temperature

  of sterilized instrument less than 0.2%.

● LCD display working status,touch keys

● The vacuum data can reach -0.8bar,it fits various instrument,including package,

  unpackaged, solid, hollow, multi-apertures and inset pipes.It makes sure the

  instrument can be sterilized completely.

● Fully computer controlled LCD display bright show.The interface is modularized

  panel for easy operation.

● It is installed with BOWIE&DICK which measures the penetration of water steam.

● It has vacuum test which can make sure the ability of vacuum testing.

● Fast and independent steam generator.

● Built-in mini printer which can record the sterilizing information

● Equipped with safety valve,safety lock door system.

● Pressure lock system,pressure or temperature overload protection alarm system.

● It inactivates the HIV,HBV,BSE,and bacillus efficiently.

● This product is designed for open water tank,water purification, sewage tank

  separation,convenient and intuitive.

● Warranty 12 months

SPECIFICATION

Sterilizing chamber volume

12L(φ200×370 mm)

18L(φ250×360 mm)

24L(φ250×470 mm)

Working pressure

0.22Mpa

Working temperature

134℃

Adjustment of temperature

105-134℃

Timer

0-99 min

Heat average

≤ ± 1℃

Power

12L: 1.8 KW / AC220V 50Hz

18L: 2KW / AC220V 50Hz

24L: 2KW / AC220V 50Hz

Dimension

12L: 560 × 470 × 400 mm

18L: 560 × 470 × 400 mm

24L: 675 × 470 × 400 mm

Package dimension

12L: 655 × 560 × 495 mm

18L: 655 × 560 × 495 mm

24L: 765 × 560 × 495 mm

G.W/N. W

12L: 48/43 kg

18L: 52/47kg

24L: 58/53kg
