Product Name:Wondcon WMV-100BWL Laptop Ultrasound Scanner
Model:WMV-100BWL
Application:
Inquiry:

Details of Wondcon WMV-100BWL Laptop Ultrasound Scanner

DETAILS

WMV-100BWL is a laptop portable veterinary black white ultrasound with the versatility and features for use in a variety of applications.

The ultrasound is optimized for use with Middle and small animals, liver, gallbladder, spleen, kidney, bladder, uterus and other tissues and organs inspection and diagnosis of lesions. Pregnancy test and measurement of backfat thickness in large animals such as cattle, sheep, horses and pigs.

Features:

● First class digital image

● Full and rich graphic information processing functions.

● Clear image:left and right flip,black and white flip,up and down flip.

● Long time cine loop, image automatic cycle playing.

● Compact size, clear image,easy.

● External USB storage, more convenient for image upload operation, strong

  endurance.

● Standard 1 probe socket. Dual probes sockets is optional

● Basic type 80 elements,high end 96 elements

● 24 months warranty


SPECIFICATION

Type: Basic Laptop BW Veterinary Ultrasound Scanner, High-end Laptop BW Veterinary Ultrasound Scanner

Body mark(Element):

Basic Laptop BW Veterinary Ultrasound Scanner: 17 types, 80kinds

High-end Laptop BW Veterinary Ultrasound Scanner: 17 types, 96 kinds

Cine loop: 512 frames

Display: 12.1 inch LCD display,the image display convenient and flexible

Keyboard: Backlit silicon keyboard,easy to operate in dark room

Scanning mode: Convex/Linear/Micro convex/Rectal

THI and histogram function: Available

Main gain: 0-100%

Smart TGC control: 8 segments

E-focus: 4

Image storage: 8G

Pseudo color: 8kinds

Scanning area(angle): 3 levels

Edge enhancement: 0-3

Linear correlation: 0-5

Dynamic range: 0-135dB

Detect depth: 307mm

OB-GYN: BPD,CRL,GS,FL,HC,AC

lithium-ion battery: 4-8 hours

Weight&size: N.W:4.3kg,G.W:9.5kg.Package dimension:47*22*40mm

Language: Chinese,English,Spanish,French,Portuguese and Russian.

Machine extended port: DICOM,USB,VGA,VIDEO


STANDARD CONFIGURATION

Main unit

6.5MHz veterinary linear rectal probe

Aluminum plastic packing box

Power adapter

OPTIONAL COFIGURATION

6.5MHz micro-convex probe

3.5MHz convex probe

7.5MHz linear probe Trolley

Puncture guide frame

Sony video printer USB storage
