Description of Wondcon WMV-200BWP Palm Ultrasound Scanner
DETAILS
Light weight, portable and easy to use.
Features:
● CNC Dynamic frequency
scanning technology
● Real time point by point dynamic acceptance focus
technology
● Various animal (cat, dog, bovine, sheep, equine, swine
etc.) liver, gallbladder, spleen, kidney,
bladder, uterus, ovary and other tissues or
organs inspection and diagnosis of lesions
● External USB storage, more convenient for image upload
● Image storage function
● Professional Software Packages for Veterinary use
● Ultra-light weight
● Over 4 hours battery
● Waterproof probe
● 24 months
warranty
Professional Software Packages for Veterinary Use
Canine - GSD, CRL, HD, BD
Feline - HD, BD
Sheep - STD, SHD, SCRL
Equine - EEGD, ECD, ESD, EBD
Swine - HLA, SLA
Bovine:
CTD, CHL ,CCRL
SPECIFICATION
General
Imaging mode B,B+B
Gray scale 255
Display 5.6 inch LED HD display
Transducer frequency 2.0-10Mhz
Transducer connector 1(standard)
Scanning depth(mm) From 46 to 208, depends on probes, adjustable
System language English
Imaging process
Pre-processing Edge enhancement,15 levels image
Post-processing up/down,left/right flip,frame correlation,focus conversion
System languague English
Function
Cine loop 255 frames
Storage media Built-in flash, External pen drive
storage 8G,min 1000 frames permanent storage
Body mark: No
Psuedo color: 8
Transducer auto-detection: Available
Standard configuration
Display
Data, week, time, transducer model,
transducer position, transducer frequency,
depth, focus position, body marks, frame
rate, measurement values, gain, etc.
Power supply: AC 100-240V 50/60 Hz and DC
Package size: 54x40x18cm
Net weight:800g
Gross
weight:4.3kg
STANDARD CONFIGURATION
Main Unit 5.6” LCD Monitor One Transducer
Connector One USB Port Two Carrying Straps
One Lithium Battery(6 hours)
One Anti-collision Master Case
Professional software packages
8G TFT card
6.5MHz veterinary rectal linear transducer
OPTIONAL CONFIGURATION
Extra Lithium Battery(6 hours)
Car adapter
Extra charger
Optional probe:5.0Mhz micro-convex
probe,3.5Mhz convex probe,7.5Mhz high
frequency linear array probe,7.5Mhz back fat
probe
Trolley
Sony video printer
USB storage
Puncture guide frame
