DETAILS
Multi-purpose
ultrasound with high image resolution and sensitivity
Features:
● 15inch LCD display
● Angle display view adjustment more flexible
● Professional animal measurement software
● Stable operation platform
● Probe interface 2 or 3 for choose
● Element:80 or 96 for choose
● Support OB report overview
● 6 kinds of language: Chinese,English,Spanish,French,Portuguese
and Russian
● Support OB report overview
● Application: less than 100kg animals inspection and
diagnosis
1) liver, gallbladder, spleen, kidney, bladder and other
tissues and organs
2) Pregnancy, fetal growth, fetal vitality and fetal
position
3) Uterus, ovary these reproductive system diagnosis of
lesions
● Backlit silicon keyboard, available for doctor use in
dark room
● 24 months
warranty
SPECIFICATION
General
Imaging mode B,B+B
Gray scale 255
Display 15 inch LED HD display
Transducer frequency 2.0-10Mhz
Transducer connector Type 1:two pockets
Type 2,three pockets
Scanning depth(mm) From 46 to 208,depends on probes,adjustable
System languague: Chinese,English,Spanish,French,Portuguese and Russian
Imaging process
Pre-processing Edge enhancement,15 levels image
Post-processing up/down,left/right flip,frame correlation,focus conversion
Function
Cine loop 255 frames
Storage media Built-in flash, External pen drive
Storage 8G, min 1000 frames permanent storage
Body mark 17 types
Psuedo color: 8
Transducer
auto-detection: Available
Display
Data, week, time, transducer model,
transducer position, transducer frequency,
depth, focus position, body marks, frame
rate, measurement values, gain, etc.
Power supply: AC 100-240V 50/60 Hz
Package size: 85*65*99cm
Machine dimension:74*52*131cm
Net weight:26.6kg
Gross
weight:40.6kg
STANDARD CONFIGURATION
Main Unit 15 LED Monitor One Transducer
Connector One USB Port Two Carrying Straps
Professional software packages
8G TFT card
6.5MHz veterinary rectal linear transducer
OPTIONAL CONFIGURATION
Optional probe:5.0Mhz micro-convex
probe,3.5Mhz convex probe,7.5Mhz high
frequency linear array probe,7.5Mhz back fat
probe
Sony video printer
USB storage
