Description of Wondcon
WMV-400CDL Laptop Color Doppler
DETAILS
Ultimate mobility,
advanced imaging technology
It is a hand-carried
color Doppler veterinary ultrasound system that allows veterinarians to
diagnose
anywhere and anytime with confidence.
Features:
● 15 inch HD LED
● Ultrasound scanner operation
system: Window operation system
● Backlight control panel
● Dynamic range:0-160dB
● Language:
Chinese,English,Spanish,French,Russian,Arabic,Vietnamese,Portuguese,Indonesian,German,Persian and Thai
● VET dedicated software: Expert
veterinary preset, measurement and body mark
● Built-in high capacity lithium
battery,battery life≥2.5 hours
● One key intelligent
optimization
● Application:canine,feline,equine,bovine,ovine
and other animals in the clinical abdomen, chest, heart,
tendon, small organs, reproduction
system, fetal and other examination
● 24 months warranty
SPECIFICATION
General
Imaging mode B, 2B, 4B, M, B/M, B/C, B/D,
B/C/D, B/CFM/D, PDI
Color, Dual Color
Simultaneous 2D/Color Compound
PW, Duplex/Triplex
CFM, CDE, PD, Directional PD, CD
Gray scale 256
Display Size (Diagonal): 15”
Contrast Ratio: 800:1
Resolution: 1024×768 pixels
Brightness: 230 cd/m2
Color Depth: 24bit
Rotate Angle: ± 90°
Grey Levels: 256
Transducer frequency 2.0-10Mhz
Transducer connector 1(standard)
Scanning depth(mm) From 46 to 208,depends on probes, adjustable
System languague EN/RU/FR/SP/PT/ARB/VN/ID/DE/FA/TH
Imaging process
Pre-processing Edge enhancement, 8 levels image
Post-processing up/down,left/right flip,frame correlation,focus
conversion
Function
Cine loop 600 frames
Storage media Built-in flash, External pen drive
storage 8G,min 1000 frames permanent storage
Body mark: 6 types
Psuedo color 8
Transducer auto-detection Available
Connectivity/Media/Peripherals
Transducer Ports: 1
USB Ports: 2
Hard Disc: 60GB (SSD) 120G/256GB SSD (Optional)
Footswitch: USB
Ethernet Port: 2(100Mb/1000Mb)
External Display: VGA/HDMI
USB
Printer,Digital Laser Printer/Digital B/W Thermal Printer
Display
Data, week, time, transducer model, transducer position,
transducer frequency, depth, focus position, body marks, frame rate,
measurement values, gain, etc.
Equipment size: 375mm×360mm×75mm
Equipment weight: 6.7kg
Packing size:60*50*27cm
Packing weight: 18kg
Power supply: AC 100-240V 50/60 Hz and DC
Condition
Operating Temperature: 5°C~40°C
Humidity: ≤80%
Pressure: 700hPa~1060hPa
Storage
Temperature: -5°C~40°C
Humidity: ≤80%
Pressure:
500hPa~1060hPa
STANDARD CONFIGURATION
Main Unit 15” LCD
Monitor One Transducer
Connector One USB Port
One Lithium Battery(2-3 hours)
Professional software
packages
8G TFT card
6.5MHz veterinary
rectal linear transducer
OPTIONAL CONFIGURATION
Extra Lithium
Battery(6 hours)
Optional probe:5.0Mhz
micro-convex
probe,3.5Mhz convex
probe,7.5Mhz high
frequency linear array
probe,7.5Mhz back fat
probe
Trolley
USB storage
