Product Name:Wondcon WMV-500CT Trolley Color Doppler
Model:WMV-500CT
Application:
Inquiry:

Description of Wondcon WMV-500CT Trolley Color Doppler

DETAILS

It is equipped with the functions of image scanning, measurement, calculation, display, query,

body mark, annotate, printing, medical records storage, edit the inspection report, system settings, etc

Features:

● Tissue harmonic imaging technology

● Professional veterinary software kits

● Breakthrough chipset technology to ensure frame rate

● The particle display reaches the quantum level

Language:Chinese,English,Spanish,French,Russian,Arabic,Vietnamese,Portuguese,Indonesian,German,

   Persian and Thai

● Silicone keyboard LED backlit

● Button:quick and easy control

● Display 360°adjustable

● Hook type probe box,humanized design

● 24 months warranty


    SPECIFICATION

General

Imaging mode B, 2B, 4B, M, B/M, B/C, B/D,

B/C/D, B/CFM/D, PDI

Color, Dual Color

Simultaneous 2D/Color Compound

PW, Duplex/Triplex

CFM, CDE, PD, Directional PD, CD

Gray scale 256

Display Type 1:

Size 17 inch

Type 2:

Size 19 inch

Rotate angle: ± 360°

Transducer frequency 2.0-10Mhz

Transducer connector 1(standard)

Scanning depth(mm) From 46 to 208, depends on probes,adjustable

System language EN/RU/FR/SP/PT/ARB/VN/ID/DE/FA/TH

Imaging process

Image optimization 7 level,visible&adjustable

Dynamic range 0-160dB,15 level visible and adjustable

Psuedo color 8

Smoothing image 7 level,visible and adjustable

Edge enhancement 8 levels,visible and adjustable

Sound power 0-15 levels, total 16 level visible and adjustable

Function

Connectivity/Media/Peripherals

Transducer Ports: 1

USB Ports: 2

Hard Disc: 60GB (SSD) 120G/256GB SSD (Optional)

Footswitch: USB

Ethernet Port: 2(100Mb/1000Mb)

External Display: VGA/HDMI

USB Printer,Digital Laser Printer/Digital B/W Thermal Printer

Display

Data, week, time, transducer model, transducer position, transducer frequency, depth, focus position, body marks, frame rate, measurement values, gain, etc.

Type 1:

87*66*130cm(main unit)

48*44*27cm(monitor)

69kg

Type 2:

102*72*153cm

126kg

Condition

Operating Temperature: 5°C~40°C

Humidity: ≤80%

Pressure: 700hPa~1060hPa

Storage

Temperature: -5°C~40°C

Humidity: ≤80%

Pressure: 500hPa~1060hPa


   STANDARD CONFIGURATION

Main Unit LCD Monitor One Transducer

Connector One USB Port

Professional software packages

6.5MHz veterinary rectal linear transducer

OPTIONAL CONFIGURATION

Optional probe:5.0Mhz micro-convex

probe,3.5Mhz convex probe,7.5Mhz high

frequency linear array probe,7.5Mhz back fat

probe
