Description of BLC-600 HD LCD Digital Camera
DETAILS
BLC-600 HD LCD Digital Camera is a brand new high performance and highly cost-effective.
Super reliable HD LCD camera which combines an full HD camera and a retina HD LCD screen.
With the built-in software, the BLC-600 can be controlled by a mouse to take pictures,
take videos and do simple measurement.
Features:
● Control camera with mouse from USB port, no shaking. 11.6” retina HD LCD
screen, high definition and high quality color reproduction.
● 6.0MP still image capture and 1080P Video Recording.
● Save image and video to SD card.
● HDMI Output from the camera to the LCD screen, frame rate up to 60f.
● Also can be connected to PC and take picture, take video, do measurement and
analyze images.
● Standard C-mount Interface for different microscopes.
● 12 months warranty
Application:
BLC-600 HDMI LCD digital camera is specifically developed for different microscopy applications.
It can be widely used in medical diagnosis, industrial production and inspection, laboratory research.
Also can be for drelated microscopy field for image, video capture and analysis.
It is mainly used for following areas:
● Biological Teaching Digital Imaging
● Live Cell Imaging
● Surgical Microscopic Imaging
● Pathology
● Cytology
● Defect Analysis
● Semiconductor Inspection
● Navigation for Processed Imaging
● Industry
SPECIFICATION
HDMI Camera
Image Sensor: CMOS, Sony IMX236
Chip Size: 1/2.8"
Video Resolution: 1920 × 1080
Captured Image Resolution:
3264 × 1836 on SD card to LCD monitor,
1920 × 1080 and 3264 × 1836 with software to PC.
Frame Rate: 1920 × 1080 30fps via USB2.0, 1920 × 1080 60fps via HDMI
Data Record: High speed SD Card (8G)
Video Record: 1080p 30fps in SD Card
1080p 30fps in PC
Scan Mode: Progressive
Electronic Shutter: Electronic Rolling Shutter
A/D conversion: 8 bit
Color Depth: 24bit
Sensitivity: 510mV
Dynamic Range: 68dB
S/N ratio: 52dB
Exposure time: 0.001 sec ~ 10.0 sec
Exposure: Auto/Manual
White balance: Auto
Settings: Gain,Gamma,Saturation,Contrast,scale bar function
Built- in software: Cloud 1.0 version
PC software: ISCapture
Output model 1: USB2.0
Output model 2: HDMI
System Compatible: Windows XP/Vista/Win 7(32 and 64-bit), MAC OSX
Optical port: C- Mount
Power Supply: DC 12/2A
Operational Temperature: 0-60°C
Humidity 45%-85%
Storage Temperature -20-70°C
Retina Screen
Screen Size: 11.6 inch
Aspect Ratio: 16:9
Display Resolution: 1920 × 1080
Display Type: IPS-PRO
Brightness: 320cd/m2
Static Contrast Ratio: 1000:1
Input: 1*HDMI PORT
Power Supply: DC 12V /2A External Adapter
Dimension: 282mm×180.5mm×15.3mm
Net Weight: 600g
