Product Name:Wondcon WMV-6000B Endoscope Video System
Model:WMV-6000B
Application:Video gastroscope & colonoscope for animal
Inquiry:

Description of Wondcon WMV-6000B Endoscope Video System

DETAILS

Video gastroscope & colonoscope for animal

Features:

● Use sony high-solution CCD with 440,000 or CMOS 1,000,000 pixels color image.

● With 30,000 hours long life LED lamp and high color temperature light cold source.

● Germany elaborated designed operation system.

● Excellent image freezing and operation system.

● With fully waterproof design.

● OEM service is available.

● 12 months warranty.


SPECIFICATION

Parameter of endoscope

Top diameter: ≤Φ8.0mm

Input tube: ≤Φ8.0mm

Biopsy channel: ≥Φ2.0mm

Working length: ≥1500mm

Total length: ≥1800mm

Field of view: ≥140o

Depth of field: ≥3-100mm

Image solution: ≥480000pixels (CCD)

Bending angles: up≥ 210odown≥90oleft&right≥100omaximum 230

Image frozen: 4 images frozen, store, playback.

Parameter of processor & light source

Contrast adjustment 0-128

Image adjustment

color adjustment level: 0-128,

vessel enhancement

Metering mode AVE/PEAK

Image enhance 0-30

White balance Auto/manual white balance

Pump: pressure 30-80Mpk, air supply 4L/min-10L/min

illuminance: ≥200000Lx,LED light source 30000hours life.

Parameter of suction device

Vessel capacity Not less than 1

Maximum suction volume 20 L / Min


CONFIGURATION

WMV-6000B video Endoscope

WMV-6000B video Endoscope 1

Water bottle interface seal ring 6

Biopsy forceps 6 Wash ear ball 1

Cleaning brush 1 Water injection bottle assembly 1

Mouth pad 3 Endoscopic box 1

Leak detector 1 Clean lid 1

Leak cover 1 Instructions 1

Attract the valve body baffle cap 2

EMV-3000 Endoscope processor & light source

(With air pump and SD record card and Rigid endoscope interface)

EMV-3000 Endoscope processor &light source(LED lamp) 1

Power cable 1

Instructions 1

Suction device 1

Suction device 1

power cable 1

Instructions 1

Trolly 1

19” LCD monitor 1
