Wondcon WMV-671A Veterinary dental X-Ray System

(High Frequency DC Portable Dental X-Ray Unit)

DETAILS

Small body, light weight and nearly no radiation excellent image quality, portable storage, save more space.

It uses high frequency and DC international power supply.

All of the components install in the central PC board concentrated.

Features:

● Lightweight dental x-ray generator is extremely portable for use in any care setting.

● There are also manual buttons installed on the surface of shell, as well as batteries and charges.

● High frequency unit operates at 60kV/1.5mA.

● Designed for convenient, one-handed operation.

● There colors for choose.

● It can connect with sensor, is great convenience.

● Generates less harmful radiation than conventional systems.

● Offers rapid imaging, reducing time between radio graphs.

● No assembly or installation required.

● 12 months warranty

SPECIFICATION

Tube voltage       60KV

Tube current       1.5mA

Exposure time     0.1--2.0s

Frequency        30KHz

Rate power       60VA

Distance from skin to cone    130mm

Tube focus                0.3mm*0.3mm

Battery                   DC14.8V 6400mAh

Charger input voltage       AC100V-240V±10%

Output voltage            DC16.8V

Ambient temperature      5℃~40℃

Relative temperature       <75%RH

Net weight                 2.5KG

Gross weight               3.5KG

Size(mm)                 138*165*185

Package size(mm)          365*330*265
