Description of Wondcon VTS32 Wound Continuous Drainage Suction Unit

Intended for negative pressure wound therapy and postoperative drainage.

Features:

● Three colors for choose

● Two operation mode: Continuous and Intermittent, working time of Intermittent mode

  can be set;

● Adopt oil-less pump, high vacuum, low noise;

● VST50D Vacuum regulator can be locked and controlled as needed.

● 12months warranty

Specification:

Model: Vts32

Max vacuum ≥32KPa(240mmHg)

Vacuum range 2.5 KPa(18.75mmHg) ～ Max

Flow rate ≥25L/min

Noise ≤50dB(A)

Working mode Continuous and Intermittent

Intermittent working time 5min On/2min Stop(default) or set from 1 ～15min

Storage bottle 1000ml(PC)

Battery type and working time —

Power supply ～ 220V,50Hz

Input power 100VA

GW/NW 8.4kg/6.8kg

Packing dimension 55cm×26.4cm×38cm
