Product Name: Wondcon WML-420A VET Veterinary 3-diff Auto Hematology Analyzer
Model:WML-420A VET
Application:
Inquiry:

 Description of Wondcon WML-420A VET Veterinary 3-diff Auto Hematology Analyzer


DETAILS

WML-420 serise auto hematology analyzer is a compact 3-diff hematology analyzer with user-friendly interface, it is designed to meet the demand of small veterinary clinics with limited space and budget, meanwhile no compromise of any performance and quality.

Features:

  • Lightweight dental x-ray generator is extremely portable for use in any care setting.
  • Animal species: Canine, Bovine, Feline, Ovine, Equine, Simian, Porcine, Murine, and 4 user-defined species.
  • Principle: Impedance for WBC, RBC, PLT counting, compact design.
  • Throughput: 35 samples per hour(A model), 60 samples per hour(B and C model).
  • 3-part differentiation of WBC, 20 parameters +3 histograms.
  • 3 counting modes: whole blood, capillary blood and prediluted.
  • Micro sample volume: 10 ul.
  • Built-in thermal printer.
  • Reagent: Diluent, Lyse, PB, cleanser,E-Z Cleanser.
  • 12months warranty.

Specification

 General Features

Model: WML-420A VET

Throughput: 35 samples/hour

Channels: 1

Aperture diameter: NO

Principle: Impedance for WBC,RBC,PLT; SFT method for HGB

Parameters: 20 parameters(including WBC, Neu#, Lym#, Mid#, Neu%,Lym%, Mid%, RBC, HGB, HCT, MCV, MCH,

MCHC,RDW-SD, RDW-CV, PLT, MPV, PDW, PCT, P-LCR)

Histograms: 3 histograms(including WBC,RBC,PLT histograms)

HGB lamp: LED 540nm

Sample volume Normal: 10ul, Prediluted: 20ul

Performance

Carry-over rate

Parameter and CV

WBC 2%

RBC 1%

HGB 2%

PLT 2%

Background

Parameter and Background

WBC 0.2×109/L

RBC 0.02×1012/L

HGB 1 g/L

HCT 0.5%

PLT 10×109/L

Standard reagent

Reagent Standard: Dilent: 20L, Lyse: 500ml

Cleanser Standard: Probe cleanser: 50ml

Software

Calibration: Manual & auto calibration

Counting modes:Venous, capilary, prediluted

Print :Auto print, manual print

LIS: Support LIS

Language: English, Spanish,Italian,Portuguese, etc


    SPECIFICATION

Input: 8 inch touch screen(WML420A,WML420B), 10.4 inch touch scree(WML420C)

Output: Internal printer, support external printer

Printer paper: 80×35mm

Interface: RS232 port, USB port, VGA port

Storage: 30,000 results with histogram

Dimension: 565mm×467mm×571mm(A,B model), 514mm×594mm×645mm (C model)

Blockage: clear High voltage, high pressure flush

Net weight: 19 KG(A,B model),23kg (C model)

Precision:

Parameter, CV, Measurement range

WBC 2.0% (4.0-15.0×109)/L

RBC 1.9% (3.5-6.0×1012)/L

HGB 1.9% (110.0-180.0g)/L

MCV 0.4% (80.0-110.0)fL

PLT 4.0% (100.0-500.0×109)/L

Linearity

Parameter, Measurement, range CV

WBC, (0-5.9×109)/L, (±0.3×109)/L

WBC,(6.0-99.9×109)/L   ±5%

RBC, (0-0.99×1012)/L, (±0.05×1012)/L

RBC, (1.0-9.99×1012)/L, ±5%

HGB, (0-99.0g)/L, (±2.0g)/L

HGB, (100.0-300.0g)/L, ±2%

PLT, (0-99×109)/L, (±8.0×109)/L

PLT,100-999×109)/L, ±10%

Work temperature: 18-35°C

Power requirement: 100240 AC, 50/60Hz

Relative humidity: 85

Atmospheric pressure: 86.0kPa-106.0kPa


    STANDARD CONFIGURATION

1 unit main unit

1 power supply

1 service manual

1 user manual

1 Set Standard reagent

( Dilent:20L/bottle, Lyse:500ml/bottle

Probe cleanser:50ml/bottle,

E-Z Cleanser: 50ml/bottle)

OPTIONAL CONFIGURATION

Keyboard

Touch pencil

Extra reagent
