Description of Wondcon WML-450 VET Veterinary Urine Analyzer

DETAILS

Wondcon WML-450 VET urine analyzer is a compact semi-auto urine analyzer with touch screen,

user-friendly software. Built-in thermal printer allows user to print results automatically.

Features

• Compact sized control box with precise small & strong
• Animal species: Canine, Feline, Equine, Bovine, Porcine, Others
• inch touch screen
• Strips: 11 parameters
• 100 samples/hour
• Dual wavelength reflectance test method
• Auto & manual test mode
• Thermal printer, auto & manual print
• Less and easy maintenance
• 12 months warranty

Specification

Gerenal technology

Test Principle:Dual wavelength reflectance method

Light Source:Cold Lamp with high brightness and long lifetime

Wavelength: 520nm,640nm,660nm

Test Mode:Single and Continuous test mode are selectableThroughput:120 Strips/Hour

Test Slot:Using Sliding Slot, Easy to clean and replace, Lower the Carryover Screen:Touch screen

Parameters:11 Parameters(Glucose, Bilirubin, Ketone, Specific Gravity,Blood,pH,Protein,Urobilinogen, Nitrite,Leukocyte, Vitamin C

Strip:Original WONDCON strip, 1 botttle: 100 strips

Specifcation

Sample type:urine

Storage:2,000 resultsInput:5 inch touch screen, support barcode

Output:Internal printerInterface:RS 232

Printer paper:57×35mm

Dimension:360mm×225mm×160mm

Software

LIS:Support LIS

Print:Auto print, manual print

Language:English

Report format:Half-quantitative, qualitative

Others

Power requirement:100～240 AC, 50/60Hz

Power:≤80VA

Work temperature:10-30°C

Relative humidity:≤ 70%

Atmospheric pressure:86.0kPa-106.0kPa

Net weight:2.5 KG

Performance

Coincidence rate:≥ 90%

Standard configuration

1 unit main machine

1 power supply

1 user manual1 service manual

1 bottle strip(100pcs/bottle)

Optional configuration

Strips (100pcs/bottle)
