Description of WML-410A Veterinary Electrolyte Analyzer

DETAILS

Easy-to-use, color touch screen electrolyte analyzer with throughput of 60 samples per hour based on ISE method.

Auto calibration, sampling, cleaning to assure accurate results.

Maintenance-free and long life electrode is another competitive feature to make it stand out for veterinary use.

Features:

● Animal species: Canine, Feline, Equine, Bovine, Porcine, Others

● Throughput: 60 samples per hour

● Sample volume:100-200μ

● LIon: K+, Na+, Cl-, iCa2+, pH, Li+,

● customized selection of ions, optional CO2

● Calibration: Automatic or On-demand

● Display: LCD

● Closed reagent, real time  monitoring reagent

● Printer: Internal thermalprinter

● Storage: Up to 50,000results

● Interface: RS-232, supportLIS

● Built-in thermal printer

● Less and easy maintenance

● 12 months warranty

SPECIFICATION

Gerenal technology

Method  Ion selective electrode

Throughput  60 samples/hour

Electrodes  K+, Na+, Cl-, iCa2+, pH, Li+ ,TCO2 optional

Parameters  K+, Na+, Cl-, iCa2+, pH, Li+,TCO2,TCa, KT,AG

Sample volume 100-200 ul

Reagent volume 200-400 ul

Parameter

Eletrode lifespan 12 months

Sample type  Serum,CSF,etc

Storage  50,000 samples

Input  5.6 inch touch screen, barcode

Output  Internal printer

Interface RS 232

Printer paper  80×35mm

Dimension  430mm×275mm×410mm

Software

Language  English，Russian

Unit  mmol/L, mg/dl

Print  Auto print, manual print

Liquid detection   Yes

Reagent inventory  detection Yes

Date Format   YYYY-MM-DD, MM-DD-YYYY, DD-MM-YYYY

Calibration  Manual & Auto calibration

Others

Power requirement  100～240 AC, 50/60Hz

Power ≤80VA

Work temperature  15-30°C

Relative humidity  20%-80%

Atmospheric pressure 86.0kPa-106.0kPa

Net weight  8KG

Performance

Linearity

Ion  Measurement range/(mmol/L) Slope/mV

K+  0.3-20.00 40-70

Na+  20.0-200.0  40-70

Cl- 20.0-200.0  40-70

iCa2+ 0.1-6.0 20-40

Li+ 0.2-5.0 20-50

PH 3.00-11.00  30-100

Carry over

Precision

Accuracy

Ion     Accuracy    CV      Linearity      Stability

K+      ≤ 2.0%  ≤ 1.0%   ≤ 2.0%      ≤ 2.0%

Na+     ≤ 2.0%  ≤ 1.0%   ≤ 2.0%      ≤ 2.0%

Cl-      ≤ 2.0%  ≤ 1.0%   ≤ 2.0%      ≤ 2.0%

 iCa2+   ≤ 2.5%  ≤ 1.5%   ≤ 2.0%      ≤ 2.5%

 Li+     ≤ 2.5%  ≤ 1.5%    ≤ 2.0%     ≤ 2.5%

pH      ≤ 2.0%  ≤ 0.5%    ≤ 2.0%     ≤ 2.0%

TCO2    ≤ 2.0%  ≤ 1.5%    ≤ 2.0%     ≤ 2.0

Reagent

DS-Ⅰ(NO.3) Standard A Standard B

Cleaning Solution

PVC Electrode Activating Solution

DS- Ref Ref. Filling Solution

DS- ISE Filling Solution

Deprotein Solution
