Description of WML-400A VET Semi-auto Coagulation Analyzer
DETAILS
Wondcon WML-400A VET is an easy-to-use semi-auto coagulation analyzer equipped with precise
pipette. Small volume of sample and reagent is needed for tests to save cost, for sure it is designed to
meet the requirement of small veterinary lab or clinics.
Features:
● Animal species: Canine, Feline, Equine, Bovine, Porcine, Others
● Parameters: PT, APTT, TT, FIB, etc.
● Principle: Clotting, optical method
● Disposable cuvette, no carry-over
● Precise electronic pipette
● Automatic start at reagent addition
● Built-in thermal printer, auto&manual print
● Less and easy maintenance
● 12 months warranty
SPECIFICATION
Gerenal technology
Principle Nephelometry
Channels 2 channels
Parameters PT, APTT, TT, FIB, etc
Lamp LED 470nm
Software
Calibration Single point, multiple point calibration
curve availlable
Print Auto print, manual print
LIS Support LIS
Language English, Portuguese, French, Spanish
Sample/Reagent
Sample volume 20-40uL
Reagent volume 20-40uL
cuvette incubation positions 12
Reagent incubation positions 5
Sampling Eletronic pipette :20-200 ul
Performance
Precision PT, APTT, FIB ≤ 5%, TT ≤ 8% (Normal
sample)
Deviation between channels ≤5%
Parameter
Input Keypad
Output Internal printer
Display 5 inch non-touch screen
Incubator temperature 37±1.0℃
Cuvette Disposable cuvette
Printer paper 57×35mm
Interface RS232 port
Storage 10,000 results
Dimension 345×325×145mm
Net weight 4.4KG
Others
Work temperature 10-30°C
Power requirement 100~240 AC, 50/60Hz
Power ≤80VA
Relative humidity ≤85﹪
Atmospheric pressure 86.0kPa-106.0kPa
Reagent
PT
APTT
TT
FIB
