Description of WML-430B VET Semi-automatic Chemistry Analyzer

DETAILS

Semi-automatic chemistry analyzer with large touch-screen and easy-to-use operation software.

Suitable for small veterinary labs, clinics.

Features:

● Animal species: Canine, Feline, Equine, Bovine, Porcine, Others

● 5-inch touch screen and keypad

● Permanent quartz flowcell

● Long-life halogen lamp

● Reaction curve real time display

● Support LIS

● Flowcell & cuvette modes

● Built-in thermal printer

● Less and easy maintenance

● 12 months warranty

SPECIFICATION

Gerenal technology

Item Descriptions

Principle Colorimetric

Method End point, Fixed time, Kinetic, Absorbance, Factor

Parameters Can program more than 200 parameters

Mode Quatz flowcell,disposable cuvette

Optical system

Photometer Filter

Lamp halogen lamp,6V 10W,2000 hours

Wavelenghts 340,380,405,505,546,578,620nm

Wavelenght accuracy ±2nm

Stray light ≤0.5%

Absorbance repeatility ≤ 1%

Half-wave width ≤12nm

Reaction system

Measure volume:32 ul

Performance

Carry over ≤1%

Precision ALT≤5%；TP≤2.5%；UREA≤3.5%

Heating system

Element Peltier

Temperature RT,30,37±0.3 ℃

Parameter

Storage 15,000 results

Input 5 inch touch screen & keypad

Output Internal printer

Interface RS 232

Printer paper 80×35mm

Dimension 355mm×330mm×175mm

Software

LIS Support LIS

Print Auto print, manual print

Language English, Portuguese, French, Spanish

Others

Power requirement 100～240 AC, 50/60Hz

Power ≤180VA

Work temperature 10-30°C

Relative humidity ≤ 85%

Atmospheric pressure 86.0kPa-106.0kPa

Net weight 5.6 KG
