Description of Wondcon WML-430A VET Compact Fully Automated Chemistry Analyzer
DETAILS
Simple, fast and accurate.
All steps are automated, and you can quickly get lab-accurate blood tests in just three easy steps.
Features:
● Accurate Result
With the photoelectric colorimetric principle, analyzer has advantages over dry biochemistry
analyzer adapted the light reaction method.Thevolume of test sample and dilution is
guaranteed by mould,without random error and cross contamination
● Little Sample Volume Required
Sample volume is only 1/10-1/20 of traditional chemistry analyzer
● Easy to Carry
0.02m3, 5Kg. The analyzer is designed in portableand space saving, using it anywhere at
anytime.
● Less Maintenance
There is no extra consumable needed, such as tube, pump, valve, saving your maintenance
expense.
● Single test up to 23 parameters The single test quantity has been enlarged form previous 14 to
present 23 parameters. It’ s unique
● Better User Experience Android system with 6.5 inch multi-touchscreen, user-friendly
interface.Multipliedlanguages are available
● More Compact and Lighter The dimension at 19*21*22CM, weight at4.2Kg
● New Design Appearance Brand new design, updated plastic toaluminium alloy, more durable
● 12 months warranty
SPECIFICATION
Sample type: Anti-coagulation whole blood, serum, plasma
Sample volume: 90-120ul
Bar code:Two-dimensional bar code
Testing time: 12minutes/sample
Testing principle:Absorption spectroscopy, transmissionturbidimetry
Testing method:End point, kinetic,xed time, turbidmetry et
Temperature:37℃±0.2℃
Absorbance:0-3.0Abs
Resolution:0.001Abs
QC&Calibrate:Real time full-auto nish
Work environment: Temperature:10-32℃ Humidity:＜85%
Light source:12V/20W, halogen tungsten lamp's life span is 2500 hours
Power supply:AC100V-240V, 50-60Hz Power Output: 15v7.0a, 105W MAX
Display:Android 6.5 inch 800*480, multi-point capacitive tscreenStorage:4G, > 100,000 results Printer:Built-in thermal printer
Connectors:2 USB ports
Weight:4.2 KG, the power adapter is 0.6kg
Order code:A00120VETEN0
Easy 3-steps Operation
All steps are designed automatically from centrifugation, dilution, quality control to test result printing.
Insert Sample (0.1cc blood)
Supportfullbloodsample,internalcentrifuge,nosamplepretreatment,only0.1mlfullblood,serumorplasmacancompletethetest.
Insert Rotor (12 minutesrunning)
Free of maintenance, easy to use in mobile space and eld.Key partsAmerican original import,internal no-liquid road, pumpvalve and other vul nerable parts
Read Result (immediately)
Using the principle of photoelectric colorimetric, no random error, no crossinfection.The instrument quality control, calibration automatic real-timecompletion
Disposable Reagent Disc
9 Veterinary Chemistry Pro les with 26 Parameters in One Solution
It is freeze-drying single-use plastic reagent disc panel with one year lifespan at the temperature of 2-8℃.
The diluent contains in the rotor.
The QR code not only include the basic information of rotor, but have the functions to update system of analyzer and to set zone code.
