Description of Wondcon External Fixator
DETAILS
1 .Rediolucent bone transportation fixacor, ensuring excellent fracture stabilization and visualization.
2.Scable fixation cross articulation ball-joint allows movernent and articulation after surgery avoidingpotential joint stiffness.
3.Rod to pin, easy assernbly. Frames can be simply assembled, modular design providing multiple optionsan number of assernblyconfigurations thus providing many variable pin placement options.
4.V1adular technique allows rapid and precise reduction during and after surgery. 5.Custom ODM service is available. Design and manufacture veterinary instruments and fixacorsaccording to surgical needs.
Mini Fixator - Universal
Code Specification
D501 85mm
D502 75mm
D503 65mm
Schanz Pin Diameter(mm) 2.0
Specification(mm) 100/15
Screw length/thread length
Clamps in L-type
Code Specification
D513 85mm
D514 75mm
D515 65mm
Schanz Pin
Diameter(mm) 2.0
Specification(mm) 100/15
Screw length/thread length
Mini Fixator - Horizontal Axis
Code
D507
Schanz Pin
Diameter(mm) 2.0
Specification(mm) 100/15
Screw length/thread length
Mini Fixator - Vertical Axis
Code
D509
Schanz Pin
Diameter(mm) 2.0
Specification(mm) 100/15
Screw length/thread length
Mini Fixator - Horizontal Axis II
Code
D511
Schanz pin
Diameter(mm) 2.0
Specification(mm) 100/15
Screw length/thread length
Miniral Fixator
Code Specification
D504 170mm
D505 95mm
D506 70mm
D517 95mm
D518 70mm
Schanz Pin
Diameter(mm) 2.0
Specification(mm) 100/15
Screw length/thread length
Wrist Fixator-Radiolucent
Code Specification
D125
Schanz Pin
Diameter(mm) 2.0
Specification(mm) 100/15
Screw length/thread length
Limb Reconstruction Fixator
Code Specification
D206 150mm
Schanz Pin
Diameter(mm) Specification(mm)
6.5/5.0 120/40
6.5/5.0 130/40
6.5/5.0 130/50
6.5/5.0 150/30
6.5/5.0 150/40
6.5/5.0 150/50
6.5/5.0 170/40
Diameter(mm) Specification(mm)
Screw length/thread length
6.5/4.5 90/30
6.5/4.5 100/30
6.5/4.5 100/40
6.5/4.5 110/40
6.5/4.5 120/30
6.5/4.5 120/40
Wrist Fixator-Radiolucent
Code 402
Schanz Pin
Diameter(mm) 4.0/3.0
Specification(mm) 70/25,80/35
Screw length/thread length
