Description of Wondcon Veterinary Bone Drill
DETAILS
Adantages
1. Whole power tool can be autoclavable.
2. Autoclavable for 135 °C (Improved type ≤ 155 °C ),with1.6Mpa,in this way the bacilli and virus which can notkilled by the suffocating will be killed.
3. Environment friendly nickel-metal hydride battery.
4. The machine has very low noise.
5.2 years warranty period
System 8000 Features
Single functional power tool, inspired designInnovation form Human mini fragrnent system. System 8000 offers a clear variety in hand-pieces forvarious applications. Such as Jacobs chuck drilling, saw blade cutting and K-wire insertion.
The device is fully autoclavable. Equipped with stable out-put, delivering exact mechanical power perforrnance technology. System 8000 has an original design for oblique angle insertion co facilitate surgical use. The device also offers a specific mode to perform a surgical veterinary osteotorny. Anatomical and lightweight, designed so chac veterinary surgeons can comfortably
hold using one hand, reducing the risk of control lass in an unexpected situation.
①8113 K-wire drill
②8101 Sagttal saw
③8102 Bone drill
④8103 Cannulaced drill
WMV 8101 Model Sagttal saw
Application:
For application in cutting bone during joint surgery.
With the perfect shape of ergonomic design,whole unit is autoclavable,motor isimported,low noise, steadily and quickly cutting,no damage for soft tissue,longservice life,be warranty for 2 years.A variety of different thickness or the length of the saw blade for your selection .Common length are 70mm,90mm and 100mm,common thickness are 0.8mm,1.0mm,1.2mm and 1.27mm,saw blade also can be customized according to your request.
Standard Configuration
1. One handpiece
2. One battery
3. One charger
4. One Aseptic battery transfer ring
5. One Operating manual
6 One Guarantee Card
Specification
Output power:≥30w Speed(r.p.m):/
Oscillations (osc/min):15000 Torque(Nm):/
Operation(V) voltage:7.2 Sterilization:135°C
Swings (°) :/ Noise(db):≤
WMV8102 Model Bone Drill
Specification
Output power:≥30w
Speed(r.p.m):0-1100
Oscillations (osc/min):/
Torque(Nm):0.9
Operation(V) voltage:7.2
Sterilization:135°C
Swings (°) :/
Noise(db):≤40
Standard Configuration
1. One handpiece
2. One battery
3. One charger
4. One Aseptic battery transfer ring
5. One Operating manual
6 One Guarantee Card
Application:
For application in drilling hole for plate and screw during trauma surgery.
With the perfect shape of ergonomic design,whole unit is autoclavable,motor isimported,low noise,high speed,high proper alignment,long service life. The machine is warranty for 2 years.
