Description of Wondcon Veterinary Bone Drill
DETAILS
System 8200 Features
System 8200 is the updated product for syscerrn 8000with the additional feature of multifunctional function. The hand-piece is compatible with several attachments, allowing quick and easy changing during surgery, for a variety different applications with the one device. Simplicity coupled with clever design.
①8200 Multi - function handpiece
②8201 Sagitcal saw attachment
③8202 Bone drill attachment
④8203 Cannulaced drill attachrnenc
⑤8202SAO AO drill attachment
⑥8213 K-wire drill attachment
⑦8209 Reciprocating saw attachment
Adantages
1. Excellent torque for prosthesis replacement surgery.
2. Powerful motors can provide the best speed andpower.
3. Extended capacity battery ensure theimplementation of efficient operation.
4. The main components are made of high-strengthstainless steel.
5. Optional external power supply system.
6. Autaclavable.
7. Single and multi-function mode for selection.
8. 2 years warranty period.
Electric Handpiece 8200
Electric: Yes
Multifunctional: Yes
Weight (with battery): ≤1000
Grams Speed: 0-15000 rpm
Power source: Battery
Sterilizable: Autoclavable
Battery
Technology: Ni-Mh
Insert/detachment method: The telescopic
The blocking mechanism: Yes
Autoclavable Aseptic Transfer Kit: Yes
Run time with battery: 30-40 min
Attachment
Sagittal saw attachment 8201
Oscillations (osc/min) 0-15000
Operation(V) voltage 7.2
Sterilization 135°C
Noise(db) ≤45
Bone drill attachment 8202
Speed(r.p.m) 0-1100
Torque(Nm) 0.9
Operation(V) voltage 7.2
Sterilization 135°C
Noise(db) ≤40
Canulate drill attachment 8203
Speed(r.p.m) 0-460
Torque(Nm) 1O
peration(V) voltage 7.2S
terilization 135°C
Noise(db) ≤40
Ao drill attachment 8202SAO
Oscillations (osc/min) 0-1100
Operation(V) voltage 7.2
Sterilization 135°C
Noise(db) ≤40
Reciprocating saw attachment 8209
Speed(r.p.m) 0-15000
Torque(Nm) /Operation(V) voltage 7.2
Sterilization 135°C
Noise(db) ≤45
K-wire drill attachment 8213
L-Speed(r.p.m) 0-1100
Torque(Nm) 1
Operation(V) voltage 7.2
Sterilization 135°C
Noise(db) ≤40
