Description of Wondcon Veterinary SPO2 ETCO2 Monitor

DETAILS

Wondcon WMV 650E Capno-H Capnograph

Pre-hospital first aid, hospital transit, emergency department, operating theater, U, NICU, sleep monitoring etc.

 Features

●3.5 inch TFT, monitoring the EtC02/C02 , Respirationrate,SPO2(Optional)

●EtC02 technology of infrared ray gas analysisv

Temperature, Pressure compensation and Zero

readjustment system, all of them insure the accuracy and stabilityv

Balance gas compensation makes minimuminfluence against other gases. v

Lung pressure and temperature compensation(BTPS compensation) is selectablev

●Very short warmup time, in15 seconds it canmeasure with complete accuratcyv

●Easy maintenance and no need to calibrate

●KPA , mmHg or % are selectable.

●Audio-optical alarm for exceeding limits and Apnea

●Solid design challenges hush conditions aspecially designed airway adapter is suitable intubated adult or infant monitoring.

●24 hours trend diagram keeps still availab after power-off

●Data output via USB port

●Optioanl data base software administratioanalysis and printing data

●Optional bluetooth module and bluetoothprinter, at any time to print wave shape and  data

●Large Capacity lithium battery for 10 hou  UPS

●Optional SPO2

●12 months warranty

Specification

Power

AC input: 50Hz/60AC power Consumption:10W

Operation

Working temperature: 5 -50°CHumidity: 30-75% ( non-condensing)

Atmospheric pressure: 55-115kPa

Battery Data

Lithium battery, rechargeable

Battery capacity: 3.6V,3800mAh, 15 hours(approximately)

Charging time: 4 hours from empty to full

Physical Data

Dimension: 72mm(W)x155mm(H) x28mm(D)Weight:main stream < 90g,monitor 250g

Respiration rate

Range: 3-150 t/min

Accuracy: the bigger value of ±1 %(reading)or ±1 times/min

Trend length: 24 hours

Flux:50-250cc/min seletable

Capnograph Measuring

DataEtC02/C02

Range: 0-150mmHg ( 0-20kPa,or 0-20% (VIV))

Accuracy:

±2mmHg when 0-40mmHg,

±5%(reading) when > 41-70mmHg

±8%(reading) when > 71-100mmHg

±10%(reading) when > 101-150mmHg

EtC02 Update: every breath,

Trend length: 24hours

Oximeter data (optional)

Oximetry saturation

Range:0-100%

Accuraty:±3% when 50-69%

±2% when 70-100%

Trend length:24 hoursPulse rateRange:30-250bpm

Accuracy:the bigger value of ±2bpm or ±2%(reading)

when 30-250bpmTrend length:24 hours

Standard configuration

Main unit,airway tube and sampling tube
